SuperWorkstation 7039A-i 1. Dual Socket P (LGA 3647) support 2nd Gen Intel® Xeon® Scalable processors (Cascade Lake/Skylake)‡2. 16 DIMMs; up to 2TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM3. 4 PCI-E 3.0 x16, 2 PCI-E 3.0 x8 slots, M.2 Interface: PCI-E 3.0 x4 M.2 Form Factor: 2260, 2280, 22110 M.2 Key: M-Key, 2 PCI-E 3.0 NVMe x4 Internal Port(s)4. 2x 1GbE LAN ports5. 7.1 HD Audio6. 4 Internal fixed 3.5" drive bays, 2 5.25" peripheral drive bays7. 1 M.2 slot, 2 NVMe support with optional cables8. 1200W High-efficiency Power Supply Platinum Level Certified Manufacturer: Supermicro Old price: $1,020.83 Price: $916.67 Qty: Add to cart Custom wishlist OK Add to wishlist Add to compare list Email a friend Product SKUs SuperWorkstation SYS-7039A-i (Black) Motherboard Super X11DAi-N Processor/Cache CPU Dual Socket P (LGA 3647) 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡,Dual UPI up to 10.4GT/s Support CPU TDP 70-205W* Cores Up to 28 Cores Note * 200W/205W CPUs are supported under certain configurations. Please contact Supermicro Technical Support for additional information about specialized system optimization Note ‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R) GPU Support Please refer to: Compatible GPU list System Memory Memory Capacity 16 DIMM slots Up to 4TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM Supports Intel® Optane™ DCPMM†† Memory Type 2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM DIMM Sizes RDIMM: 64GB LRDIMM: 64GB 3DS LRDIMM: 128GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) Note †† Cascade Lake only. Contact your Supermicro sales rep for more info. On-Board Devices Chipset Intel® C621 chipset SATA SATA3 (6Gbps); RAID 0, 1, 5, 10 Network Controllers Dual LAN with GbE from C621 IPMI ASPEED AST2500 Audio RealTek ALC888 7.1 High Definition Audio with S/PDIF header Input / Output SATA 10 SATA3 (6Gbps) ports NVMe 2 NVMe support with optional cables LAN 2 RJ45 Gigabit Ethernet LAN ports USB 6 USB 3.0 ports (4 rear, 2 front) 2 USB 3.1 ports (rear) Audio 7.1 HD Audio with optical S/PDIF Video 1 VGA port Serial Port / Header 1 COM port (header) DOM 2 SuperDOM (Disk on Module) ports TPM 1 TPM 2.0 Header System BIOS BIOS Type UEFI 128M Management Software Intel® Node Manager IPMI 2.0 SSM, SPM, SUM SuperDoctor® 5 Watchdog PC Health Monitoring CPU Monitors for CPU Cores, Chipset Voltages, Memory. 4+1 Phase-switching voltage regulator FAN Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors Temperature Monitoring for CPU and chassis environment Thermal Control for fan connectors Chassis Form Factor Mid-Tower Model CSE-732D3-1200B Dimensions and Weight Height 16.7" (424mm) Width 7.6" (193mm) Depth 20.68" (525.3mm) Gross Weight 40 lbs (18.1 kg) Available Colors Black Front Panel Buttons Power On/Off button LEDs Power LED Hard drive activity LED Network activity LED System Information LED Ports 2 front USB 3.0 Ports 2 front HD/AC97 Audio Ports Expansion Slots PCI-Express 4 PCI-E 3.0 x16 slots 2 PCI-E 3.0 x8 slots M.2 M.2 Interface: PCI-E 3.0 x4 Form Factor: 2260, 2280, 22110 Key: M-Key Drive Bays Internal 4 Fixed 3.5" drive bays(90° rotatable drive cage) Enterprise SATA HDD only recommended Peripheral Bay 2x 5.25" standard drive bays 4x 2.5" fixed drive bays (optional) System Cooling Fans 1x 12cm rear exhaust fan 1x 12cm front cooling fan Optimized cooling technology for Whisper-Quiet Operation Power Supply 1200W high-efficiency power supply w/ PMBus AC Input 1000W: 100-114.9 V, 50-60 Hz, 12 Amp 1200W: 114.9-240 V, 50-60 Hz, 12-8 Amp DC Output1000W max1200W max +3.3V / +5V / +12V / -12V / +5VSB 20A / 20A / 83A / 0.3A / 3A 20A / 20A / 99A / 0.3A / 3A Note: Max. continuous combined load on +3.3V and +5V output shall not exceed 120W. Certification Platinum Certified Operating Environment / Compliance RoHS RoHS Compliant Environmental Spec. Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
